Compliant with the latest WPC Qi V1.2.4 standard, supports 3-coil wireless charging. Compatible with A28 & MP-A8 coils, custom coil design solutions available for customers. Multiple power output options: 6W, 7.5W Apple fast charge, 10W Samsung fast charge, 15W high-power charging.

Adopts Analogping technology to detect wireless receivers and establish communication to initiate power delivery. It scans all coils via Analogping, identifies the receiver position by signal strength, and automatically charges with the coil featuring the strongest signal.

Decodes communication packets transmitted from the receiver, and adjusts coil output power precisely via PID algorithm by tuning oscillation frequency. Power transmission will stop automatically once the receiver battery is fully charged.

High integration design with built-in full-bridge driver, dual-channel ASK communication demodulation modules for voltage and current signals. Effectively reduces overall solution size and lowers BOM cost.

Built-in complete safety & communication logic, ideal for multi-coil car wireless chargers, desktop charging pads and custom wireless charging hardware development.
